| PartNumber | WEO012864GG |
| Znamka | Winstar |
| Velikost | 2.4 |
| Aplikacija | Handheld & PDA I |
| Resolucija | 128×64 |
| Sestava | PM-OLED, OLED |
| Svetlost | |
| CR | |
| Barve | Mono(Green) |
| Osvetlitev ozadja | self |
| Vmesnik | 8-bit |
| znamka | Winstar |
| model | WEO012864GG |
| velikost diagonale | 2.4 inch |
| vrsta | PM-OLED, OLED |
| slikovnih pik | 128×64 59PPI |
| konfiguracijo | Rectangle |
| aktivno območje | 55.01(H)×27.49(V) mm |
| obris dim. | 60.5(H)×37(V) ×2.15(D) mm |
| območje okvirja | 57.01(H)×28.9(V) mm |
| zdravljenje | - |
| smer pogleda | Symmetry |
| odzivni čas | - |
| vidni kot | - |
| način delovanja | - |
| podpira barvo | Mono(Green) |
| Izvor svetlobe | self |
| utež | - |
| namenjen za | Handheld & PDA Instruments & Meters |
| hitrost sličic | - |
| plošča na dotik | Without |
| detajl d-ic | COG Built-in SSD1309ZC |
| tip vmesnika | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 30 pins FPC |
| napajanje | 3.0V (Typ.) |
