| PartNumber | WEO012864BG |
| Znamka | Winstar |
| Velikost | 1.54 |
| Aplikacija | Handheld & PDA Instr |
| Resolucija | 128×64 |
| Sestava | PM-OLED , OLED |
| Svetlost | |
| CR | |
| Barve | Mono(Green) |
| Osvetlitev ozadja | self |
| Vmesnik | 8-bit |
| znamka plošče | Winstar |
| velikost plošče | 1.54" |
| resolucija | 128×64, 92PPI |
| prikazno območje | 35.056(W)×17.52(H) mm |
| velikost obrisa | 42.24(W)×29.14(H) mm |
| vidni kot | - |
| najboljši pogled na | Symmetry |
| barve zaslona | Mono(Green) |
| pogostost | - |
| voznik ic | COG Built-in SSD1305Z |
| teža plošče | - |
| signalni vmesnik | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 24 pins FPC |
| vhodna napetost | 3.0V (Typ.) |
| okolju | Operating Temp.: -40 ~ 80 °C ; Storage Temp.: -40 ~ 85 °C |
| panelni model | WEO012864BG |
| vrsta plošče | PM-OLED , OLED |
| slikovnih pik | Rectangle |
| odprtina okvirja | 37.056(W)×19.52(H) mm |
| površino | - |
| način prikaza | - |
| odzivni čas | - |
| tip svetilke | self |
| zaslon na dotik | Without |
| aplikacija | Handheld & PDA Instruments & Meters Comm Device Home Appliance Healthcare |
