| PartNumber | WEO012832DW |
| Znamka | Winstar |
| Velikost | 0.91 |
| Aplikacija | Wearable Instruments |
| Resolucija | 128×32 |
| Sestava | PM-OLED , OLED |
| Svetlost | |
| CR | |
| Barve | Mono(White) |
| Osvetlitev ozadja | self |
| Vmesnik | 4-wire |
| znamka | Winstar |
| velikost diagonale | 0.91 inch |
| slikovnih pik | 128×32 145PPI |
| aktivno območje | 22.38(H)×5.584(V) mm |
| območje okvirja | 24.384(H)×7.58(V) mm |
| smer pogleda | Symmetry |
| vidni kot | - |
| podpira barvo | Mono(White) |
| utež | - |
| hitrost sličic | - |
| detajl d-ic | COG Built-in SSD1306BZ |
| tip vmesnika | 4-wire SPI , 15 pins FPC |
| napajanje | 3.0V (Typ.) |
| model | WEO012832DW |
| vrsta | PM-OLED , OLED |
| konfiguracijo | Rectangle |
| obris dim. | 30(H)×11.5(V) ×1.75(D) mm |
| zdravljenje | - |
| odzivni čas | - |
| način delovanja | - |
| Izvor svetlobe | self |
| namenjen za | Wearable Instruments & Meters |
| plošča na dotik | Without |
