| PartNumber | WEH002002BW |
| Znamka | Winstar |
| Velikost | 5.7 |
| Aplikacija | Instruments & Me |
| Resolucija | 20×23 |
| Sestava | PM-OLED, OLED |
| Svetlost | |
| CR | |
| Barve | Mono(White) |
| Osvetlitev ozadja | self |
| Vmesnik | CPU/SPI |
| znamka plošče | Winstar |
| panelni model | WEH002002BW |
| velikost plošče | 5.7" |
| vrsta plošče | PM-OLED, OLED |
| format prikaza | 20 characters × 2 lines, 3PPI |
| format pisave | 5×8 dots |
| velikost znakov | 6×9.66(W×H) mm |
| višina znakov | 7.32×10.98(W×H) mm |
| prikazno območje | 145.08(W)×20.64(H) mm |
| odprtina okvirja | 149.0(W)×23.0(H) mm |
| velikost obrisa | 180(W)×40(H) ×9.3(D) mm |
| površino | - |
| vidni kot | - |
| način prikaza | - |
| najboljši pogled na | Symmetry |
| odzivni čas | - |
| barve zaslona | Mono(White) |
| tip svetilke | self |
| pogostost | - |
| zaslon na dotik | Without |
| voznik ic | COBBuilt-in WS0010 |
| teža plošče | - |
| aplikacija | Instruments & Meters |
| signalni vmesnik | CPU/SPI , 16 pins Pad |
| vhodna napetost | 5.0V (Typ.) |
