| PartNumber | WEH001602DB |
| Znamka | Winstar |
| Velikost | 2.3 |
| Aplikacija | Instruments & Me |
| Resolucija | 5×8 |
| Sestava | OLED, PM-OLED |
| Svetlost | |
| CR | |
| Barve | Mono(Blue) |
| Osvetlitev ozadja | self |
| Vmesnik | |
| proizvajalec | Winstar |
| ime modela | WEH001602DB |
| velikost zaslona | 2.3 inch |
| vrsto zaslona | OLED, PM-OLED |
| char številka | 16 characters × 2 lines 7PPI |
| format char | 5×8 dots |
| korak (mm) | 3.6×6.3 (H×V) |
| velikost črk (mm) | 2.95×5.55 (H×V) |
| aktivna površina (mm) | 56.95 × 11.85 (H×V) |
| obris (mm) | 85 × 30 × 10 (H×V×D) |
| površina okvirja (mm) | 66 × 16 (H×V) |
| zdravljenje | - |
| vidni kot | - |
| odgovor | - |
| dober pogled na | Symmetry |
| način dela | - |
| barvna globina | Mono(Blue) |
| osvetlitev ozadja | self |
| masa | - |
| uporablja za | Instruments & Meters |
| hitrost osveževanja | - |
| zaslon na dotik | Without |
| 5.0V (Typ.) |
