| PartNumber | WEG010032BW |
| Znamka | Winstar |
| Velikost | 2.4 |
| Aplikacija | Instruments & Me |
| Resolucija | 100×32 |
| Sestava | PM-OLED, OLED |
| Svetlost | |
| CR | |
| Barve | Mono(White) |
| Osvetlitev ozadja | self |
| Vmesnik | CPU/SPI |
| znamka plošče | Winstar |
| panelni model | WEG010032BW |
| velikost plošče | 2.4" |
| vrsta plošče | PM-OLED, OLED |
| resolucija | 100×32, 43PPI |
| slikovnih pik | Rectangle |
| prikazno območje | 58.95(W)×19.15(H) mm |
| odprtina okvirja | 77(W)×25.2(H) mm |
| velikost obrisa | 98(W)×60(H) ×10(D) mm |
| površino | - |
| vidni kot | - |
| način prikaza | - |
| najboljši pogled na | Symmetry |
| odzivni čas | - |
| barve zaslona | Mono(White) |
| tip svetilke | self |
| pogostost | - |
| zaslon na dotik | Without |
| voznik ic | COG Built-in WS0010 |
| teža plošče | - |
| aplikacija | Instruments & Meters |
| signalni vmesnik | CPU/SPI , 16 pins FPC |
| vhodna napetost | 5.0V (Typ.) |
