| PartNumber | V650HP1-LS6 Rev.E8 |
| Znamka | Innolux |
| Velikost | 65 |
| Aplikacija | TV Sets |
| Resolucija | 1920×1080 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 5000:1 |
| Barve | 1.07B |
| Osvetlitev ozadja | 4 |
| Vmesnik | LVDS |
| proizvajalec | Innolux |
| ime modela | V650HP1-LS6 Rev.E8 |
| velikost zaslona | 65 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1920(RGB)×1080 (FHD) 34PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 1428.48 × 803.52 (H×V) |
| obris (mm) | 1450.5 × 828.52 × 30.8 (H×V×D) |
| površina okvirja (mm) | 1435.5 × 810.52 (H×V) |
| zdravljenje | Antiglare (Haze 1%), Hard coating (3H) |
| svetilnost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 5000 : 1 (Typ.) (TM) |
| vidni kot | 88/88/88/88 (Typ.)(CR≥20) |
| odgovor | 6.5 (Typ.)(G to G) ms |
| dober pogled na | Symmetry |
| način dela | Super MVA, Normally Black, Transmissive |
| barvna globina | 1.07B 100% sRGB |
| osvetlitev ozadja | 4 strings WLED , 30K hours , With LED Driver |
| masa | 23.0±1.2Kgs |
| uporablja za | TV Sets |
| hitrost osveževanja | 120Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (4 ch, 10-bit) , Connector 102 pins |
| napajanje z napetostjo | 12.0V (Typ.) |
| maks. ocene | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
