| PartNumber | V500HJ1-PE8 Rev.C3 |
| Znamka | Chimei Innolux |
| Velikost | 50 |
| Aplikacija | Transparent Display |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD , CELL |
| Svetlost | |
| CR | 5000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | LVDS |
| znamka plošče | Chimei Innolux |
| velikost plošče | 50" |
| resolucija | 1920(RGB)×1080, FHD, 44PPI |
| prikazno območje | 1095.84(W)×616.41(H) mm |
| velikost obrisa | 1112.32(W)×631.61(H) ×1.31(D) mm |
| svetlost | 0 cd/m² |
| vidni kot | 88/88/88/88 (Typ.)(CR≥20) |
| najboljši pogled na | Symmetry |
| globina stekla | 0.50+0.50 mm |
| barve zaslona | 16.7M 70% NTSC |
| pogostost | 60Hz |
| voznik ic | COF Built-in 6 source + 4 gate chips |
| teža plošče | 1.99±0.19Kgs |
| signalni vmesnik | LVDS (2 ch, 8-bit) , 51 pins Connector |
| vhodna napetost | 12.0V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panelni model | V500HJ1-PE8 Rev.C3 |
| vrsta plošče | a-Si TFT-LCD , CELL |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | Antiglare (Haze 1%), Hard coating (3H) |
| kontrastno razmerje | 5000:1 (Typ.) (TM) |
| način prikaza | Super MVA, Normally Black, Transmissive |
| odzivni čas | 8.5 (Typ.)(G to G) |
| transmisivnost | 5.6% (Typ.)(with Polarizer) |
| tip svetilke | No B/L |
| zaslon na dotik | Without |
| aplikacija | Transparent Display |
| LC500DUE-SFR1 | LG Display | 50 | 1920×1080 |
| LC500EUD-FFF3 | LG Display | 50 | 1920×1080 |
| T500HVN04.1 CELL | AUO | 50 | 1920×1080 |
| T500HVN04.5 CELL | AUO | 50 | 1920×1080 |
| T500QVN01.1 CELL | AUO | 50 | 3840×2160 |
| V500HJ1-L01 | Innolux | 50 | 1920×1080 |
| V500HJ1-LE6 | Innolux | 50 | 1920×1080 |
| V500HJ1-PE6 | Innolux | 50 | 1920×1080 |
| V500HJ1-PE8 | Innolux | 50 | 1920×1080 |
| V500HK1-LS6 Rev.C7 | Innolux | 50 | 1920×1080 |
