| PartNumber | V500DJ7-QE1 |
| Znamka | Innolux |
| Velikost | 50 |
| Aplikacija | TV Sets |
| Resolucija | 3840×2160 |
| Sestava | a-Si TFT-LCD, CELL |
| Svetlost | |
| CR | 4000:1 |
| Barve | 1.07B |
| Osvetlitev ozadja | No |
| Vmesnik | V-by-One |
| znamka plošče | Innolux |
| panelni model | V500DJ7-QE1 |
| velikost plošče | 50" |
| vrsta plošče | a-Si TFT-LCD, CELL |
| resolucija | 3840(RGB)×2160, UHD, 89PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 1095.84(W)×616.41(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 1106.84(W)×628.01(H) ×1.32(D) mm |
| površino | Antiglare (Haze 1%), Hard coating (3H) |
| svetlost | 0 cd/m² |
| kontrastno razmerje | 4000:1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način prikaza | Super MVA, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 9.5 (Typ.)(G to G) |
| globina stekla | - |
| transmisivnost | 5.0% (Typ.)(with Polarizer) |
| barve zaslona | 1.07B 70% NTSC |
| tip svetilke | No B/L |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| voznik ic | COF Built-in 12 source chips |
| teža plošče | 2.11±0.20Kgs |
| aplikacija | TV Sets |
| signalni vmesnik | V-by-One 8 lane , 51 pins Connector |
| vhodna napetost | 12.0V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
