| PartNumber | UG-6448HLBEG03 |
| Znamka | WiseChip |
| Velikost | 0.66 |
| Aplikacija | |
| Resolucija | 64×48 |
| Sestava | OLED |
| Svetlost | 100 |
| CR | 10000:1 |
| Barve | Mono(Blue) |
| Osvetlitev ozadja | self |
| Vmesnik | CPU/SPI/I²C |
| znamka plošče | WiseChip |
| panelni model | UG-6448HLBEG03 |
| vrsta plošče | PM-OLED , OLED |
| velikost plošče | 0.66 inch |
| resolucija | 64×48 |
| aktivno območje | 13.42×10.06 mm |
| oris | 18.46×18.1×1.55 mm |
| površino | |
| svetlost | 100 cd/m² (Typ.) |
| kontrastno razmerje | 10000 : 1 (Typ.) |
| barve zaslona | Mono(Blue) (1-bit) |
| vidni kot | |
| voznik ic | COG Built-in SSD1306 |
| signalni vmesnik | 8-bit 6800/8080 parallel, 4-wire SPI, I²C, 28 pins |
| vhodna napetost | 2.8/7.25V (Typ.)(VDD/VCC) |
