| PartNumber | TX43D14VC0CAB |
| Znamka | KOE |
| Velikost | 17.0 |
| Aplikacija | DMPC |
| Resolucija | 1280×1024 |
| Sestava | LCM |
| Svetlost | 230 |
| CR | 400:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | HITACHI |
| panelni model | TX43D14VC0CAB |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 17.0 inch |
| resolucija | 1280(RGB)×1024 , SXGA |
| način prikaza | IPS-Pro, Normally Black, Transmissive |
| aktivno območje | 337.92×270.336 mm |
| oris | 368×306 mm |
| površino | Antiglare |
| svetlost | 230 cd/m² (Typ.) |
| kontrastno razmerje | 400:1 (Typ.) |
| barve zaslona | 16.7M (6-bit + Hi-FRC) |
| odzivni čas | 20/20 (Typ.)(Tr/Td) |
| vidni kot | |
| pogostost | 60Hz |
| tip svetilke | 4 pcsCCFLWithout Driver |
| signalni vmesnik | LVDS (2 ch, 8-bit), 30 pins |
| vhodna napetost | 5.0V (Typ.) |
| aplikacija | DMPC |
