| PartNumber | TX20D33VM2BAC |
| Znamka | KOE |
| Velikost | 8.0 |
| Aplikacija | Industrial |
| Resolucija | 800×480 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 600:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | CMOS |
| proizvajalec | KOE |
| velikost zaslona | 8.0 inch |
| število slikovnih pik | 800(RGB)×480 (WVGA) 116PPI |
| aktivna površina (mm) | 174 × 104.4 (H×V) |
| površina okvirja (mm) | 187.0 × 108.4 (H×V) |
| svetilnost | - |
| vidni kot | 80/80/60/80 (Typ.)(CR≥10) |
| dober pogled na | 6 o'clock |
| barvna globina | 262K |
| masa | 160g |
| hitrost osveževanja | 60Hz |
| vrsto signala | CMOS (1 ch, 6-bit) , 40 pins Connector |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| ime modela | TX20D33VM2BAC |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 189 × 120 × 8 (H×V×D) |
| zdravljenje | - |
| kontrastno razmerje | 600 : 1 (Typ.) (TM) |
| odgovor | 20 (Typ.)(Tr+Td) ms |
| način dela | TN, Normally White, Transmissive |
| osvetlitev ozadja | WLED , 50K hours , No Driver |
| uporablja za | Industrial |
| zaslon na dotik | Without |
