| PartNumber | TX18D211VM0BAA |
| Znamka | KOE |
| Velikost | 7.0 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 800×480 |
| Sestava | LTPS TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | KOE |
| panelni model | TX18D211VM0BAA |
| velikost plošče | 7.0" |
| vrsta plošče | LTPS TFT-LCD, LCM |
| resolucija | 800(RGB)×480, WVGA, 133PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 152.4(W)×91.44(H) mm |
| odprtina okvirja | 156.2(W)×94.5(H) mm |
| velikost obrisa | 167.7(W)×109.5(H) ×20.3(D) mm |
| površino | - |
| svetlost | 1200 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način prikaza | IPS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| barve zaslona | 262K 73% NTSC |
| tip svetilke | WLED , 50K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | 219g (Typ.) |
| aplikacija | Industrial Outdoor High Brightness Automotive Display |
| signalni vmesnik | LVDS (1 ch, 6-bit) , 20 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
