| PartNumber | TX18D210VM0BAA |
| Znamka | KOE |
| Velikost | 7.0 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 800×480 |
| Sestava | LCM , LTPS TFT-LCD |
| Svetlost | |
| CR | 1200:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | Parallel |
| proizvajalec | KOE |
| velikost zaslona | 7.0 inch |
| število slikovnih pik | 800(RGB)×480 (WVGA) 133PPI |
| aktivna površina (mm) | 152.4 × 91.44 (H×V) |
| površina okvirja (mm) | 156.2 × 94.5 (H×V) |
| svetilnost | 800 cd/m² (Typ.) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| dober pogled na | Symmetry |
| barvna globina | 262K 72% NTSC |
| masa | 214g (Typ.) |
| hitrost osveževanja | 60Hz |
| vrsto signala | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| ime modela | TX18D210VM0BAA |
| vrsto zaslona | LCM , LTPS TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 167.7 × 109.5 × 20.3 (H×V×D) |
| zdravljenje | - |
| kontrastno razmerje | 1200 : 1 (Typ.) (TM) |
| odgovor | 30 (Typ.)(Tr+Td) ms |
| način dela | IPS, Normally Black, Transmissive |
| osvetlitev ozadja | WLED , 50K hours , With LED Driver |
| uporablja za | Industrial Outdoor High Brightness Automotive Display |
| zaslon na dotik | Without |
