| PartNumber | TX11D201VM0BAA |
| Znamka | KOE |
| Velikost | 4.2 |
| Aplikacija | Automotive Display |
| Resolucija | 480×272 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1500:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | Parallel |
| znamka | KOE |
| model | TX11D201VM0BAA |
| velikost diagonale | 4.2 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 480(RGB)×272 [WQVGA] 131PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 92.88(H)×52.632(V) mm |
| obris dim. | 102.5(H)×69(V) ×15.5(D) mm |
| območje okvirja | 95.28(H)×55.07(V) mm |
| zdravljenje | Antiglare, Hard coating (2H) |
| svetilnost | 750 cd/m² (Typ.) |
| kontrastno razmerje | 1500:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način delovanja | IPS, Normally Black, Transmissive |
| podpira barvo | 16.7M 65% NTSC |
| Izvor svetlobe | WLED [6S1P] , 50K hours , With LED Driver |
| utež | 97.0g (Typ.) |
| namenjen za | Automotive Display |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | Parallel RGB (1 ch, 8-bit) , 68 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
