| PartNumber | TV097QXM-NU0 |
| Znamka | BOE |
| Velikost | 9.7 |
| Aplikacija | Pad & Tablet |
| Resolucija | 1536×2048 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 6S6P |
| Vmesnik | MIPI |
| proizvajalec | BOE |
| ime modela | TV097QXM-NU0 |
| velikost zaslona | 9.7 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1536(RGB)×2048 (QXGA) 264PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 147.456 × 196.608 (H×V) |
| obris (mm) | 152.536 × 206.548 × 3.2 (H×V×D) |
| svetilnost | 460 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Min.)(CR≥10) |
| odgovor | 30 (Max.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | ADS, Normally Black, Transmissive |
| barvna globina | 16.7M 72% NTSC |
| osvetlitev ozadja | 6S6P WLED , No Driver |
| masa | 110g (Max.) |
| uporablja za | Pad & Tablet |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | MIPI (2 ch, 4 data lanes) , Connector 61 pins |
| napajanje z napetostjo | 1.8/5.5/-5.5V (Typ.)(VCC/AVDD/AVEE) |
| maks. ocene | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
