| PartNumber | TV080WXM-NS1 |
| Znamka | BOE |
| Velikost | 8.0 |
| Aplikacija | Pad & Tablet |
| Resolucija | 800×1280 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 1100:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka | BOE |
| velikost diagonale | 8.0 inch |
| slikovnih pik | 800(RGB)×1280 [WXGA] 188PPI |
| aktivno območje | 107.64(H)×172.224(V) mm |
| svetilnost | 530 cd/m² (Typ.) |
| smer pogleda | Symmetry |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| podpira barvo | 16.7M 87% NTSC |
| utež | - |
| hitrost sličic | 60Hz |
| tip vmesnika | MIPI (4 data lanes) , 34 pins Connector |
| napajanje | 1.8/5.4/-5.4V (Typ.)(VDD1/PVDD/NVDD) |
| okolju | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -30 ~ 80 °C |
| model | TV080WXM-NS1 |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 114.65(H)×183.853(V) ×3.56(D) mm |
| kontrastno razmerje | 1100:1 (Typ.) (TM) |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| način delovanja | ADS, Normally Black, Transmissive |
| Izvor svetlobe | WLED [3 strings] , W/O Driver |
| namenjen za | Pad & Tablet |
| plošča na dotik | Without |
| AT080TN42 | Innolux | 8.0 | 800×600 |
| L5F30614T64 | SANYO | 8.0 | 800×480 |
| LB080WV4-A1 | LG Display | 8.0 | 800×480 |
| LT080EE04100 | TOSHIBA | 8.0 | 1600×768 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| PD080SL1 | E Ink | 8.0 | 800×600 |
| PD080SL5 | E Ink | 8.0 | 800×600 |
| TM080SV-22L03 | SANYO | 8.0 | 800×600 |
| TM080VG-22L01 | SANYO | 8.0 | 640×480 |
| TV080WXM-NL0 | BOE | 8.0 | 800×1280 |
