| PartNumber | TV080WUM-NH1 |
| Znamka | BOE |
| Velikost | 8.0 |
| Aplikacija | Pad & Tablet |
| Resolucija | 1200×1920 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 850:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka | BOE |
| model | TV080WUM-NH1 |
| velikost diagonale | 8.0 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1200(RGB)×1920 [WUXGA] 283PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 107.64(H)×172.224(V) mm |
| obris dim. | - |
| svetilnost | - |
| kontrastno razmerje | 850:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način delovanja | ADS, Normally Black, Transmissive |
| podpira barvo | 16.7M |
| Izvor svetlobe | WLED |
| utež | - |
| namenjen za | Pad & Tablet |
| hitrost sličic | 60Hz |
| plošča na dotik | - |
| tip vmesnika | MIPI (4 data lanes) , 39 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
