| PartNumber | TM150TDSG80 |
| Znamka | TIANMA |
| Velikost | 15.0 |
| Aplikacija | Industrial |
| Resolucija | 1024×768 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | TIANMA |
| panelni model | TM150TDSG80 |
| velikost plošče | 15.0" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1024(RGB)×768, XGA, 85PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 304.128(W)×228.096(H) mm |
| odprtina okvirja | 307.4(W)×231.3(H) mm |
| velikost obrisa | 326.5(W)×253.5(H) ×10(D) mm |
| površino | Antiglare |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| način prikaza | TN, Normally White, Transmissive |
| najboljši pogled na | 12 o'clock |
| odzivni čas | 8 (Typ.)(Tr+Td) |
| barve zaslona | 262K/16.7M 60% NTSC |
| tip svetilke | WLED , 30K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | TBD |
| aplikacija | Industrial |
| signalni vmesnik | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -10 ~ 65 °C ; Storage Temp.: -20 ~ 65 °C |
