| PartNumber | TM123XDHP90 |
| Znamka | TIANMA |
| Velikost | 12.3 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 1920×720 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 10S4P |
| Vmesnik | LVDS |
| znamka plošče | TIANMA |
| panelni model | TM123XDHP90 |
| velikost plošče | 12.3" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1920(RGB)×720, 166PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 292.32(W)×109.62(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 311(W)×130(H) ×15.7(D) mm |
| površino | Antiglare (Haze 28%) |
| svetlost | 1000 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| vidni kot | - |
| način prikaza | SFT, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| barve zaslona | 16.7M 98% sRGB |
| tip svetilke | 10S4P WLED , 10K hours , Without Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | 490g (Typ.) |
| aplikacija | Industrial Outdoor High Brightness Automotive Display |
| signalni vmesnik | LVDS (2 ch, 8-bit) , 50 pins FPC |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
