| PartNumber | TM116VDSP03 |
| Znamka | TIANMA |
| Velikost | 11.6 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 1920×1080 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 900:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 9S6P |
| Vmesnik | LVDS |
| proizvajalec | TIANMA |
| ime modela | TM116VDSP03 |
| velikost zaslona | 11.6 inch |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| število slikovnih pik | 1920(RGB)×1080 (FHD) 190PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 256.32 × 144.18 (H×V) |
| obris (mm) | 273.5 × 166.5 × 11.5 (H×V×D) |
| površina okvirja (mm) | 259.31 × 148.73 (H×V) |
| zdravljenje | Hard coating |
| svetilnost | 1000 cd/m² (Typ.) |
| kontrastno razmerje | 900 : 1 (Typ.) (TM) |
| vidni kot | 88/88/88/88 (Typ.)(CR≥10) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | SFT, Normally Black, Transmissive |
| barvna globina | 16.7M 70% NTSC |
| osvetlitev ozadja | 9S6P WLED , 50K hours , No Driver |
| masa | TBD |
| uporablja za | Industrial Outdoor High Brightness |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (2 ch, 8-bit) , 30 pins Connector |
| napajanje z napetostjo | 3.3/10.7/20/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| maks. ocene | Storage Temp.: -30 ~ 85 °C Operating Temp.: -20 ~ 70 °C |
