| PartNumber | TM101DDHG05 |
| Znamka | TIANMA |
| Velikost | 10.1 |
| Aplikacija | Industrial |
| Resolucija | 1024×600 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka | TIANMA |
| velikost diagonale | 10.1 inch |
| slikovnih pik | 1024(RGB)×600 [WSVGA] 117PPI |
| aktivno območje | 222.72(H)×125.28(V) mm |
| območje okvirja | - |
| svetilnost | 1400 cd/m² (Typ.) |
| smer pogleda | 12 o'clock |
| vidni kot | 80/80/75/80 (Typ.)(CR≥10) |
| podpira barvo | 262K/16.7M 47% NTSC |
| utež | - |
| hitrost sličic | 60Hz |
| model | TM101DDHG05 |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 235(H)×143(V) ×7.8(D) mm |
| zdravljenje | Antiglare, Hard coating |
| kontrastno razmerje | 500:1 (Typ.) (TM) |
| odzivni čas | 7/9 (Typ.)(Tr/Td) |
| način delovanja | TN, Normally White, Transmissive |
| Izvor svetlobe | WLED [14S3P] , 30K hours , W/O Driver |
| namenjen za | Industrial |
| plošča na dotik | Without |
| AM-1280800N1TZQW-T06H | AMPIRE | 10.1 | 1280×800 |
| B101EW05 V0 | AUO | 10.1 | 1280×800 |
| BT101IW02 V.0 | Innolux | 10.1 | 1024×600 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
| HSD101PFW2-C00 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-H00 | HannStar | 10.1 | 1280×800 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
