| PartNumber | TM080RDHG30 |
| Znamka | TIANMA |
| Velikost | 8.0 |
| Aplikacija | Industrial |
| Resolucija | 800×480 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | 3S12P |
| Vmesnik | |
| znamka plošče | TIANMA |
| velikost plošče | 8.0" |
| resolucija | 800(RGB)×480, WVGA, 116PPI |
| prikazno območje | 176.64(W)×99.36(H) mm |
| svetlost | 450 cd/m² (Typ.) |
| vidni kot | 70/70/60/70 (Typ.)(CR≥10) |
| najboljši pogled na | - |
| barve zaslona | 262K/16.7M |
| pogostost | 60Hz |
| utež | - |
| panelni model | TM080RDHG30 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| kontrastno razmerje | 500:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| tip svetilke | 3S12P WLED , 20K hours , Without Driver |
| zaslon na dotik | Without |
| aplikacija | Industrial |
