| PartNumber | TM070RDSG12 |
| Znamka | TIANMA |
| Velikost | 7.0 |
| Aplikacija | Industrial |
| Resolucija | 800×480 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | 7S3P |
| Vmesnik | |
| proizvajalec | TIANMA |
| ime modela | TM070RDSG12 |
| velikost zaslona | 7.0 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 800(RGB)×480 (WVGA) 133PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 152.4 × 91.44 (H×V) |
| obris (mm) | 167 × 106.3 × 9.8 (H×V×D) |
| površina okvirja (mm) | 154.4 × 93.44 (H×V) |
| zdravljenje | Antiglare |
| svetilnost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| odgovor | 20 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | SFT, Normally Black, Transmissive |
| barvna globina | 262K/16.7M 70% NTSC |
| osvetlitev ozadja | 7S3P WLED , 50K hours , With LED Driver |
| masa | 175g (Typ.) |
| uporablja za | Industrial |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
