| PartNumber | TM070RDSG08 |
| Znamka | TIANMA |
| Velikost | 7.0 |
| Aplikacija | Industrial |
| Resolucija | 800×480 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | 10S3P |
| Vmesnik | LVDS |
| proizvajalec | TIANMA |
| velikost zaslona | 7.0 inch |
| število slikovnih pik | 800(RGB)×480 (WVGA) 133PPI |
| aktivna površina (mm) | 152.4 × 91.44 (H×V) |
| površina okvirja (mm) | 155.4 × 94.44 (H×V) |
| svetilnost | 500 cd/m² (Typ.) |
| vidni kot | 70/70/70/60 (Typ.)(CR≥10) |
| dober pogled na | - |
| barvna globina | 262K/16.7M 70% NTSC |
| masa | 176g (Typ.) |
| hitrost osveževanja | 60Hz |
| vrsto signala | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ime modela | TM070RDSG08 |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 166.4 × 107.2 × 8.5 (H×V×D) |
| zdravljenje | Antiglare |
| kontrastno razmerje | 500 : 1 (Typ.) (TM) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| način dela | TN, Normally White, Transmissive |
| osvetlitev ozadja | 10S3P WLED , 50K hours , With LED Driver |
| uporablja za | Industrial |
| zaslon na dotik | Without |
