| PartNumber | TM070RDHG34 |
| Znamka | TIANMA |
| Velikost | 7.0 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 800×480 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 3S8P |
| Vmesnik | |
| proizvajalec | TIANMA |
| ime modela | TM070RDHG34 |
| velikost zaslona | 7.0 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 800(RGB)×480 (WVGA) 134PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 154.08 × 85.92 (H×V) |
| obris (mm) | 164.9 × 100 × 6 (H×V×D) |
| površina okvirja (mm) | 157.08 × 89.39 (H×V) |
| zdravljenje | Antiglare |
| svetilnost | 1000 cd/m² (Typ.) |
| kontrastno razmerje | 800 : 1 (Typ.) (TM) |
| vidni kot | 70/70/60/70 (Typ.)(CR≥10) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| dober pogled na | 6 o'clock |
| način dela | TN, Normally White, Transmissive |
| barvna globina | 16.7M 50% NTSC |
| osvetlitev ozadja | 3S8P WLED , 50K hours , No Driver |
| masa | TBD |
| uporablja za | Industrial Outdoor High Brightness Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
