| PartNumber | TM070RDHG25 |
| Znamka | TIANMA |
| Velikost | 7.0 |
| Aplikacija | Industrial |
| Resolucija | 800×480 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 262K |
| Osvetlitev ozadja | 3S8P |
| Vmesnik | |
| znamka plošče | TIANMA |
| velikost plošče | 7.0" |
| resolucija | 800(RGB)×480, WVGA, 134PPI |
| prikazno območje | 154.08(W)×85.92(H) mm |
| velikost obrisa | 164.9(W)×100(H) ×8.1(D) mm |
| svetlost | 450 cd/m² (Typ.) |
| vidni kot | 80/80/60/80 (Typ.)(CR≥10) |
| najboljši pogled na | 6 o'clock |
| barve zaslona | 262K 50% NTSC |
| pogostost | 60Hz |
| utež | TBD |
| panelni model | TM070RDHG25 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | 157.08(W)×89.39(H) mm |
| površino | Antiglare |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 15 (Typ.)(Tr+Td) |
| tip svetilke | 3S8P WLED , 20K hours , Without Driver |
| zaslon na dotik | Without |
| aplikacija | Industrial |
