| PartNumber | TM047XDZP02 |
| Znamka | Tianma |
| Velikost | 4.7 |
| Aplikacija | MPH |
| Resolucija | 540×960 |
| Sestava | LCM |
| Svetlost | 400 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka plošče | TIANMA |
| panelni model | TM047XDZP02 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 4.7 inch |
| resolucija | 540(RGB)×960 , qHD |
| način prikaza | SFT, Normally Black, Transmissive |
| aktivno območje | 58.32×103.68 mm |
| oris | 62.72×113.53×1.78 mm |
| površino | |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193170% |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 5S2PWLEDWithout Driver |
| signalni vmesnik | MIPI (2 data lanes), 24 pins |
| vhodna napetost | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| aplikacija | MPH |
