| PartNumber | TM035HDHP13 |
| Znamka | TIANMA |
| Velikost | 3.5 |
| Aplikacija | Outdoor High Brightn |
| Resolucija | 240×320 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka plošče | TIANMA |
| velikost plošče | 3.5" |
| resolucija | 240(RGB)×320, QVGA, 114PPI |
| prikazno območje | 53.28(W)×71.04(H) mm |
| velikost obrisa | 64(W)×85(H) mm |
| svetlost | 1000 cd/m² (Typ.) |
| vidni kot | 88/88/88/88 (Typ.)(CR≥10) |
| najboljši pogled na | Symmetry |
| barve zaslona | 262K 60% NTSC |
| utež | - |
| panelni model | TM035HDHP13 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | Antiglare |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| način prikaza | SFT, Normally Black, Transmissive |
| odzivni čas | - |
| tip svetilke | WLED , 20K hours |
| aplikacija | Outdoor High Brightness Handheld & PDA |
