| PartNumber | TM026HDH02 |
| Znamka | TIANMA |
| Velikost | 2.6 |
| Aplikacija | Mobile Phone |
| Resolucija | 240×320 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 500:1 |
| Barve | 65K/262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| proizvajalec | TIANMA |
| ime modela | TM026HDH02 |
| velikost zaslona | 2.6 inch |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| število slikovnih pik | 240(RGB)×320 (QVGA) 156PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 38.88 × 51.84 (H×V) |
| obris (mm) | - |
| svetilnost | 240 cd/m² (Typ.) |
| kontrastno razmerje | 500 : 1 (Typ.) (TM) |
| vidni kot | 70/70/70/60 (Typ.)(CR≥10) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| dober pogled na | 6 o'clock |
| način dela | TN, Normally White, Transmissive |
| barvna globina | 65K/262K 60% NTSC |
| osvetlitev ozadja | WLED , No Driver |
| masa | TBD |
| uporablja za | Mobile Phone |
| hitrost osveževanja | - |
| zaslon na dotik | Without |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 60 °C |
| A026EAN01.0 | AUO | 2.6 | 800×1280 |
| AMDM001 | Samsung | 2.6 | 240×400 |
| AMS260CM61 | Samsung | 2.6 | 240×320 |
| L5F30774P01 | Epson | 2.6 | 240×320 |
| LS026B8PX04 | SHARP | 2.6 | 240×400 |
| LS026Q3DX01 | SHARP | 2.6 | 240×320 |
| LS026Q7UX01 | SHARP | 2.6 | 320×240 |
| TD026TTEA1 | TPO | 2.6 | 480×640 |
