| PartNumber | T390XVN01.0 CELL |
| Znamka | AUO |
| Velikost | 39 |
| Aplikacija | LCTV |
| Resolucija | 1366×768 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | 5000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No B/L |
| Vmesnik | LVDS |
| znamka plošče | AUO |
| panelni model | T390XVN01.0 CELL |
| vrsta plošče | a-Si TFT-LCD , CELL |
| velikost plošče | 39 inch |
| resolucija | 1366(RGB)×768 , WXGA |
| način prikaza | AMVA, Normally Black, Transmissive |
| aktivno območje | 853.409×479.808 mm |
| oris | 868.72×492.83 mm |
| površino | Antiglare (Haze 2%), Hard coating (3H) |
| globina stekla | 0.50+0.50 mm |
| transmisivnost | 8.0% (Typ.)(with Polarizer) |
| kontrastno razmerje | 5000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit) |
| odzivni čas | 6.5 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| signalni vmesnik | LVDS (1 ch, 8-bit), 30 pins |
| vhodna napetost | 12.0V (Typ.) |
| aplikacija | LCTV |
