| PartNumber | STCG057QVLAM-G02-S |
| Znamka | Kyocera |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 320×240 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 700:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | Parallel |
| znamka | Kyocera |
| model | STCG057QVLAM-G02-S |
| velikost diagonale | 5.7 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 320(RGB)×240 [QVGA] 70PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 115.2(H)×86.4(V) mm |
| obris dim. | 144(H)×104.8(V) ×13.5(D) mm |
| območje okvirja | 118.4(H)×89.0(V) mm |
| zdravljenje | Glare (Haze 0%) |
| svetilnost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) (TM) |
| smer pogleda | - |
| odzivni čas | 10/25 (Typ.)(Tr/Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥5) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 262K 60% NTSC |
| Izvor svetlobe | WLED , 40K hours , W/O Driver |
| utež | 158g (Typ.) |
| namenjen za | Industrial |
| hitrost sličic | - |
| plošča na dotik | Without |
| tip vmesnika | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
