| PartNumber | STCG057QVLAD-G00 |
| Znamka | Kyocera |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 320×240 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | Parallel |
| proizvajalec | Kyocera |
| ime modela | STCG057QVLAD-G00 |
| velikost zaslona | 5.7 inch |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| število slikovnih pik | 320(RGB)×240 (QVGA) 70PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 115.2 × 86.4 (H×V) |
| obris (mm) | - |
| površina okvirja (mm) | - |
| zdravljenje | Glare (Haze 0%) |
| svetilnost | - |
| kontrastno razmerje | 500 : 1 (Typ.) (TM) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥5) |
| odgovor | 10/25 (Typ.)(Tr/Td) ms |
| dober pogled na | - |
| način dela | TN, Normally White, Transmissive |
| barvna globina | 262K |
| osvetlitev ozadja | WLED |
| masa | - |
| uporablja za | Industrial |
| hitrost osveževanja | - |
| zaslon na dotik | 4-wire Resistive Touch |
| vrsto signala | Parallel RGB (1 ch, 6-bit) |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
