| PartNumber | ST5461B03-6 |
| Znamka | CSOT |
| Velikost | 55 |
| Aplikacija | TV Sets |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD, CELL |
| Svetlost | |
| CR | 4000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | LVDS |
| znamka | CSOT |
| model | ST5461B03-6 |
| velikost diagonale | 55 inch |
| vrsta | a-Si TFT-LCD, CELL |
| slikovnih pik | 1920(RGB)×1080 [FHD] 40PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 1209.6(H)×680.4(V) mm |
| obris dim. | 1223.6(H)×697.1(V) ×1.35(D) mm |
| območje okvirja | - |
| zdravljenje | Antiglare (Haze 2%), Hard coating (3H) |
| svetilnost | 0 cd/m² |
| kontrastno razmerje | 4000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 7 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način delovanja | HVA, Normally Black, Transmissive |
| debelina plošče | 0.50+0.50 mm |
| prepustnost | 6.5% (Typ.)(with Polarizer) |
| podpira barvo | 16.7M 72% NTSC |
| Izvor svetlobe | No B/L |
| utež | 3.50Kgs (Max.) |
| namenjen za | TV Sets |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| detajl d-ic | COF Built-in 6 source + 8 gate chips |
| tip vmesnika | LVDS (2 ch, 8-bit) , 51 pins Connector |
| napajanje | 12.7V (Typ.) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| LC550WUB-SCA1 | LG Display | 55 | 1920×1080 |
| LC550WUD-SCA1 | LG Display | 55 | 1920×1080 |
| P550HVN06.0 | AUO | 55 | 1920×1080 |
| ST5461B03-1 | CSOT | 55 | 1920×1080 |
| ST5461B05-1 | CSOT | 55 | 1920×1080 |
| ST5461B05-2 | CSOT | 55 | 1920×1080 |
| ST5461D01-1 | CSOT | 55 | 3840×2160 |
| ST5461D04-2 | CSOT | 55 | 3840×2160 |
| T546HB01 V0 | AUO | 55 | 1920×1080 |
| T546HW01 V1 | AUO | 55 | 1920×1080 |
