| PartNumber | SG2701B01-3 |
| Znamka | CSOT |
| Velikost | 27.0 |
| Aplikacija | Desktop Monitor Gami |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD, CELL |
| Svetlost | |
| CR | 4000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | LVDS |
| znamka | CSOT |
| model | SG2701B01-3 |
| velikost diagonale | 27.0 inch |
| vrsta | a-Si TFT-LCD, CELL |
| slikovnih pik | 1920(RGB)×1080 [FHD] 81PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 597.888(H)×336.312(V) mm |
| obris dim. | 608.888(H)×348.337(V) ×1.3(D) mm |
| območje okvirja | - |
| zdravljenje | Antiglare (Haze 25%) |
| svetilnost | 0 cd/m² |
| kontrastno razmerje | 4000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 12 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način delovanja | HVA, Normally Black, Transmissive |
| debelina plošče | 0.40+0.50 mm |
| prepustnost | 4.6% (Typ.)(with Polarizer) |
| podpira barvo | 16.7M 99% sRGB |
| Izvor svetlobe | No B/L |
| utež | - |
| namenjen za | Desktop Monitor Gaming |
| hitrost sličic | 165Hz |
| plošča na dotik | Without |
| detajl d-ic | COF Built-in 6 source chips |
| tip vmesnika | LVDS (4 ch, 8-bit) , 61 pins Connector |
| napajanje | 12.0V (Typ.) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
