| PartNumber | RX420-Z15 |
| Znamka | ROGIN |
| Velikost | 42 |
| Aplikacija | PID |
| Resolucija | 1920×1080 |
| Sestava | LCM |
| Svetlost | 1500 |
| CR | 1200:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | ROGIN |
| panelni model | RX420-Z15 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 42 inch |
| resolucija | 1920(RGB)×1080 , FHD |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 927.94×521.96 mm |
| oris | 956.4×555 mm |
| površino | Antiglare (Haze 1%), Hard coating (2H) |
| svetlost | 1500 cd/m² (Typ.) |
| kontrastno razmerje | 1200:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193168% |
| odzivni čas | 6 (Typ.)(G to G) |
| vidni kot | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDEmbedded (LED Driver) |
| signalni vmesnik | LVDS (2 ch, 10-bit), 51 pins |
| vhodna napetost | 12.0V (Typ.) |
| aplikacija | PID |
