| PartNumber | QV116FHB-N81 |
| Znamka | BOE |
| Velikost | 11.6 |
| Aplikacija | Industrial |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD, CELL |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | eDP |
| znamka | BOE |
| model | QV116FHB-N81 |
| velikost diagonale | 11.6 inch |
| vrsta | a-Si TFT-LCD, CELL |
| slikovnih pik | 1920(RGB)×1080 [FHD] 190PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 256.32(H)×144.18(V) mm |
| obris dim. | 260.32(H)×152.08(V) ×1.06(D) mm |
| območje okvirja | - |
| zdravljenje | Antiglare (Haze 25%), Hard coating (3H) |
| svetilnost | 0 cd/m² |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način delovanja | ADS, Normally Black, Transmissive |
| debelina plošče | 0.50+0.50 mm |
| prepustnost | - |
| podpira barvo | 16.7M |
| Izvor svetlobe | No B/L |
| utež | TBD |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| detajl d-ic | COG Built-in 4 source chips |
| tip vmesnika | eDP (2 Lanes) , 30 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
