| PartNumber | PJ050IA-05L |
| Znamka | Innolux |
| Velikost | 5.0 |
| Aplikacija | Mobile Phone |
| Resolucija | 720×1280 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 6S2P |
| Vmesnik | MIPI |
| proizvajalec | Innolux |
| ime modela | PJ050IA-05L |
| velikost zaslona | 5.0 inch |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| število slikovnih pik | 720(RGB)×1280 (WXGA) 294PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 62.1 × 110.4 (H×V) |
| obris (mm) | 64.18 × 117.56 × 1.42 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Glare (Haze 0%), Hard coating (3H) |
| svetilnost | 450 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | AAS, Normally Black, Transmissive |
| barvna globina | 16.7M 72% NTSC |
| osvetlitev ozadja | 6S2P WLED , No Driver |
| masa | 17.2g |
| uporablja za | Mobile Phone |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | MIPI (4 data lanes) , 30 pins Connector |
| napajanje z napetostjo | 1.8/5.4/-5.4V (Typ.)(VDDI/AVDD/AVEE) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
