| PartNumber | P101DCZ-3Z0 |
| Znamka | Innolux |
| Velikost | 10.1 |
| Aplikacija | Pad & Tablet |
| Resolucija | 800×1280 |
| Sestava | CELL , a-Si TFT-LC |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | MIPI |
| proizvajalec | Innolux |
| velikost zaslona | 10.1 inch |
| število slikovnih pik | 800(RGB)×1280 (WXGA) 150PPI |
| aktivna površina (mm) | 135.36 × 216.576 (H×V) |
| površina okvirja (mm) | - |
| svetilnost | 0 cd/m² |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| dober pogled na | Symmetry |
| debelina stekla | - |
| barvna globina | 16.7M 59% NTSC |
| masa | - |
| hitrost osveževanja | 60Hz |
| vrsto signala | MIPI (4 data lanes) , 40 pins Connector |
| napajanje z napetostjo | 3.3/5.8/-5.8V (Typ.)(VDDIN/AVDD/AVEE) |
| maks. ocene | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| ime modela | P101DCZ-3Z0 |
| vrsto zaslona | CELL , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | - |
| zdravljenje | Clear, Hard coating (3H) |
| kontrastno razmerje | 800 : 1 (Typ.) (TM) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| način dela | AAS, Normally Black, Transmissive |
| transmisivnost | 4.73% (Typ.)(with Polarizer) |
| osvetlitev ozadja | No B/L |
| uporablja za | Pad & Tablet |
| zaslon na dotik | Without |
