| PartNumber | P0650VGF1MA10 |
| Znamka | TIANMA |
| Velikost | 6.5 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 640×480 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 900:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | 6S2P |
| Vmesnik | LVDS |
| znamka plošče | TIANMA |
| panelni model | P0650VGF1MA10 |
| velikost plošče | 6.5" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 640(RGB)×480, VGA, 122PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 132.48(W)×99.36(H) mm |
| odprtina okvirja | 135.48(W)×102.36(H) mm |
| velikost obrisa | 153(W)×118(H) ×11.2(D) mm |
| površino | Antiglare |
| svetlost | 800 cd/m² (Typ.) |
| kontrastno razmerje | 900:1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način prikaza | SFT, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| barve zaslona | 262K/16.7M 70% NTSC |
| tip svetilke | 6S2P WLED , 70K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | TBD |
| aplikacija | Industrial Outdoor High Brightness Automotive Display |
| signalni vmesnik | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.0G (19.6 m/s²) |
