| PartNumber | NV156FHM-N6B |
| Znamka | BOE |
| Velikost | 15.6 |
| Aplikacija | Laptop |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1500:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 11S4P |
| Vmesnik | eDP |
| znamka plošče | BOE |
| panelni model | NV156FHM-N6B |
| velikost plošče | 15.6" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1920(RGB)×1080, FHD, 141PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 344.16(W)×193.59(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 350.66(W)×205.24(H) ×5(D) mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 1500:1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način prikaza | HADS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| barve zaslona | 16.7M 100% sRGB |
| tip svetilke | 11S4P WLED , 15K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| slog oblike | Slim (PCBA Bent, T≤3.0mm) |
| aplikacija | Laptop |
| signalni vmesnik | eDP (2 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 30 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B156XTN04.1 | AUO | 15.6 | 1366×768 |
| B156XTN05.0 | AUO | 15.6 | 1366×768 |
| B156XTT01.0 | AUO | 15.6 | 1366×768 |
| HB156WX1-100 | BOE | 15.6 | 1366×768 |
| LP156WH1-TLC1 | LG Display | 15.6 | 1366×768 |
| LTN156AT30-B02 | Samsung | 15.6 | 1366×768 |
| N156HGE-L11 | Innolux | 15.6 | 1920×1080 |
| NV156FHM-N41 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N42 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N43 | BOE | 15.6 | 1920×1080 |
