| PartNumber | NV156FHM-AW1 |
| Znamka | BOE |
| Velikost | 15.6 |
| Aplikacija | Laptop |
| Resolucija | 1920×1080 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 9S6P |
| Vmesnik | |
| proizvajalec | BOE |
| ime modela | NV156FHM-AW1 (BOE0678) |
| velikost zaslona | 15.6 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1920(RGB)×1080 (FHD) 141PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 344.16 × 193.59 (H×V) |
| obris (mm) | 379.9 × 233.6 × 4.47 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Antiglare |
| svetilnost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 800 : 1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| odgovor | 30 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | ADS, Normally Black, Transmissive |
| barvna globina | 16.7M 72% NTSC |
| osvetlitev ozadja | 9S6P WLED , 15K hours , With LED Driver |
| obrisna oblika | Flat (PCBA Flat, T3.4~4.0mm) |
| uporablja za | Laptop |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Electromagnetic Digitizer |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
