| PartNumber | NV116WHM-T04 |
| Znamka | BOE |
| Velikost | 11.6 |
| Aplikacija | Laptop |
| Resolucija | 1366×768 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 262K |
| Osvetlitev ozadja | 8S3P |
| Vmesnik | eDP |
| znamka plošče | BOE |
| panelni model | NV116WHM-T04 (BOE0965) |
| velikost plošče | 11.6" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1366(RGB)×768, WXGA, 135PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 256.125(W)×144(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 278(W)×168(H) ×3.2(D) mm |
| površino | Glare (Haze 0%), Hard coating (3H) |
| svetlost | 250 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način prikaza | ADS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 20 (Typ.)(Tr+Td) |
| barve zaslona | 262K 50% NTSC |
| tip svetilke | 8S3P WLED , 15K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | On-Cell Touch |
| slog oblike | Slim (PCBA Flat, T≤3.2mm) |
| aplikacija | Laptop |
| signalni vmesnik | eDP (1 Lane) , eDP1.2 , HBR1 (2.7G/lane) , 40 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
