| PartNumber | NV116WHM-A23 |
| Znamka | BOE |
| Velikost | 11.6 |
| Aplikacija | Laptop |
| Resolucija | 1366×768 |
| Sestava | a-Si TFT-LCD , Assem |
| Svetlost | |
| CR | 800:1 |
| Barve | 262K |
| Osvetlitev ozadja | 6S4P |
| Vmesnik | |
| znamka plošče | BOE |
| velikost plošče | 11.6" |
| resolucija | 1366(RGB)×768, WXGA, 135PPI |
| prikazno območje | 256.125(W)×144(H) mm |
| velikost obrisa | 287.7(W)×185.6(H) ×4.05(D) mm |
| svetlost | 200 cd/m² (Typ.) |
| vidni kot | 80/80/80/80 (Min.)(CR≥10) |
| najboljši pogled na | Symmetry |
| barve zaslona | 262K 50% NTSC |
| pogostost | 60Hz |
| slog oblike | Slim (PCBA Flat, T≤3.2mm) |
| panelni model | NV116WHM-A23 (BOE0744) |
| vrsta plošče | a-Si TFT-LCD , Assembly |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | Anti-Scatter, Hard coating (7H) |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| način prikaza | - |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| tip svetilke | 6S4P WLED , 15K hours , With LED Driver |
| zaslon na dotik | PCAP, Optical Bonding |
| aplikacija | Laptop |
| B116XAN03.0 HW3A | AUO | 11.6 | 1366×768 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| LP116WH1-TLP1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| M116NWR1 R1 | IVO | 11.6 | 1366×768 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| M116NWR6 R0 | IVO | 11.6 | 1366×768 |
| N116BGE-EB2 Rec.C3 | Innolux | 11.6 | 1366×768 |
| N116BGE-L42 | Innolux | 11.6 | 1366×768 |
