| PartNumber | NT116WHM-N23 |
| Znamka | BOE |
| Velikost | 11.6 |
| Aplikacija | Laptop |
| Resolucija | 1366×768 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | 8S3P |
| Vmesnik | |
| proizvajalec | BOE |
| ime modela | NT116WHM-N23 (BOE066B) |
| velikost zaslona | 11.6 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1366(RGB)×768 (WXGA) 135PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 256.125 × 144 (H×V) |
| obris (mm) | 268 × 172.98 × 3 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Glare (Haze 0%), Hard coating (3H) |
| svetilnost | 220 cd/m² (Typ.) |
| kontrastno razmerje | 500 : 1 (Typ.) (TM) |
| vidni kot | 45/45/20/40 (Typ.)(CR≥10) |
| odgovor | 12 (Typ.)(Tr+Td) ms |
| dober pogled na | 6 o'clock |
| način dela | TN, Normally White, Transmissive |
| barvna globina | 262K 45% NTSC |
| osvetlitev ozadja | 8S3P WLED , 15K hours , With LED Driver |
| obrisna oblika | Slim (PCBA Flat, T≤3.2mm) |
| uporablja za | Laptop |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| B116XTN02.3 HW0A | AUO | 11.6 | 1366×768 |
| B116XW03 V0 | AUO | 11.6 | 1366×768 |
| LP116WH4-SLN2 | LG Display | 11.6 | 1366×768 |
| N116B6-L02 | Innolux | 11.6 | 1366×768 |
| N116BGE-L11 | Innolux | 11.6 | 1366×768 |
| NT116WHM-N11 | BOE | 11.6 | 1366×768 |
| NT116WHM-N21 | BOE | 11.6 | 1366×768 |
| NT116WHM-N22 | BOE | 11.6 | 1366×768 |
| NT116WHM-N31 | BOE | 11.6 | 1366×768 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
