| PartNumber | NL12880BC20-25F |
| Znamka | NLT |
| Velikost | 12.1 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 1280×800 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 800:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | 3 |
| Vmesnik | LVDS |
| proizvajalec | NLT |
| ime modela | NL12880BC20-25F |
| velikost zaslona | 12.1 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1280(RGB)×800 (WXGA) 124PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 261.12 × 163.2 (H×V) |
| obris (mm) | 277.7 × 180.6 × 9.2 (H×V×D) |
| površina okvirja (mm) | 266.1 × 168.2 (H×V) |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | 1600 cd/m² (Typ.) |
| kontrastno razmerje | 800 : 1 (Typ.) (TM) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| odgovor | 15 (Typ.)(Tr+Td) ms |
| dober pogled na | 6 o'clock |
| način dela | TN, Normally White, Transmissive |
| barvna globina | 262K/16.7M 50% NTSC |
| osvetlitev ozadja | 3 strings WLED , 60K hours , No Driver |
| masa | 470g (Typ.) |
| uporablja za | Industrial Outdoor High Brightness |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| AA121SL09 | Mitsubishi | 12.1 | 800×600 |
| HX121WX1-101 | HYDIS | 12.1 | 1280×800 |
| LP121WX3-TLA1 | LG Display | 12.1 | 1280×800 |
| LP121WX3-TPB1 | LG Display | 12.1 | 1280×800 |
| LQ121S1DG21 | SHARP | 12.1 | 800×600 |
| LQ121S1DG42 | SHARP | 12.1 | 800×600 |
| LQ121S1LG44 | SHARP | 12.1 | 800×600 |
| LTD121EQ3B | TOSHIBA | 12.1 | 1280×800 |
| N121IA-L02 | Innolux | 12.1 | 1280×800 |
| TM121SV-A01 | SANYO | 12.1 | 800×600 |
