| PartNumber | NL10276BC20-08 |
| Znamka | NLT |
| Velikost | 10.4 |
| Aplikacija | IA |
| Resolucija | 1024×768 |
| Sestava | LCM |
| Svetlost | 300 |
| CR | 700:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | NEC |
| panelni model | NL10276BC20-08 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 10.4 inch |
| resolucija | 1024(RGB)×768 , XGA |
| način prikaza | SA-SFT, Normally Black, Transmissive |
| aktivno območje | 210.4×157.8 mm |
| oris | 227×174.5 mm |
| površino | Clear, Hard coating (3H) |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193140% |
| odzivni čas | 13/12 (Typ.)(Tr/Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 2 pcsCCFLWithout Driver |
| signalni vmesnik | LVDS (1 ch, 6-bit), 20 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | IA |
