| PartNumber | NE156QUM-N64 |
| Znamka | BOE |
| Velikost | 15.6 |
| Aplikacija | Laptop |
| Resolucija | 3840×2160 |
| Sestava | Oxide TFT-LCD , LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 10S6P |
| Vmesnik | eDP |
| znamka plošče | BOE |
| velikost plošče | 15.6" |
| resolucija | 3840(RGB)×2160, UHD, 283PPI |
| prikazno območje | 344.218(W)×193.622(H) mm |
| velikost obrisa | 350.52(W)×205.92(H) ×4.6(D) mm |
| svetlost | 350 cd/m² (Typ.) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| najboljši pogled na | Symmetry |
| barve zaslona | 16.7M 72% NTSC |
| pogostost | 60Hz |
| slog oblike | Slim (PCBA Bent, T≤3.0mm) |
| signalni vmesnik | eDP (4 Lanes) , eDP1.4a , HBR2 (5.4G/lane) , 40 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panelni model | NE156QUM-N64 (BOE07D9) |
| vrsta plošče | Oxide TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | Antiglare |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| način prikaza | ADS, Normally Black, Transmissive |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| tip svetilke | 10S6P WLED , 15K hours , With LED Driver |
| zaslon na dotik | Without |
| aplikacija | Laptop |
