| PartNumber | NE133QDM-N60 |
| Znamka | BOE |
| Velikost | 13.3 |
| Aplikacija | Laptop |
| Resolucija | 2560×1600 |
| Sestava | Oxide TFT-LCD, LCM |
| Svetlost | |
| CR | 1500:1 |
| Barve | 1.06B |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka | BOE |
| model | NE133QDM-N60 (BOE0958) |
| velikost diagonale | 13.3 inch |
| vrsta | Oxide TFT-LCD, LCM |
| slikovnih pik | 2560(RGB)×1600 [WQXGA] 227PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 286.08(H)×178.8(V) mm |
| obris dim. | 291.08(H)×195.3(V) ×2.5(D) mm |
| območje okvirja | - |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 1500:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način delovanja | ADS, Normally Black, Transmissive |
| podpira barvo | 1.06B 100% sRGB |
| Izvor svetlobe | WLED [11S5P] , 15K hours , With LED Driver |
| slog oblike | Slim (PCBA Flat, T≤3.2mm) |
| namenjen za | Laptop |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | eDP (4 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 40 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
