| PartNumber | NE133FHM-N57 |
| Znamka | BOE |
| Velikost | 13.3 |
| Aplikacija | Laptop |
| Resolucija | 1920×1080 |
| Sestava | Oxide TFT-LCD , LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 10S6P |
| Vmesnik | eDP |
| znamka plošče | BOE |
| velikost plošče | 13.3" |
| resolucija | 1920(RGB)×1080, FHD, 166PPI |
| prikazno območje | 293.76(W)×165.24(H) mm |
| velikost obrisa | 298.76(W)×181.33(H) ×2.44(D) mm |
| svetlost | 400 cd/m² (Typ.) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| najboljši pogled na | Symmetry |
| barve zaslona | 16.7M 100% DCI-P3 |
| pogostost | 60Hz |
| slog oblike | Slim (PCBA Flat, T≤3.2mm) |
| signalni vmesnik | eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 30 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 70 °C |
| panelni model | NE133FHM-N57 (BOE087A) |
| vrsta plošče | Oxide TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | - |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| način prikaza | FFS, Normally Black, Transmissive |
| odzivni čas | 25 (Typ.)(Tr+Td); 25 (Typ.)(G to G) |
| tip svetilke | 10S6P QLED , 15K hours , Without Driver |
| zaslon na dotik | Without |
| aplikacija | Laptop |
